Decision of the design start position
63
Chapter 4
1
2
3
4
5
6
7
8
9
10
11
(2) To execute
When the tracing is impossible due to the design size exceeding the embroidery space, follow the procedure
below after checking the size of the design.
(a) The frame will move again after temporary stop.
(b) Code No.225 will be displayed.
Press E key.
(c) Move the frame to the design start position.
(d) Perform tracing again.
To suspend tracing, follow the procedure below.
(a) Suspend the operation by the stop switch.
Code No.1C1 will be displayed.
Do not turn OFF the power while the code No.1C1 is displayed.
(b) Press E key.
(c) After that, follow the message described below.
"YES">>SET
"NO">>E
OK to continue tracing?
To continue → SET key
To suspend → E key
