Takeuchi TL150 Workshop Manual

IV-45
HYDRAULIC UNITSCONTROL VALVE
SECTION "X-X"
XX
810574653
9
810 34
1
7
2
T7D201E
SECTION "X-X"
XX
810574653
9
810 34
1
7
2
T7D201E
SECTION "X-X"
XX
810574653
9
10 3
1
7
2
T7D203E
Lift Arm Section
Bucket Section
Auxiliary Section
1. Load Check Valve
2. Spring
3. Cover
4. Screw
5. Spring Holder
6. Spring
7. Cap Screw
8. O-ring
9. O-ring
10. O-ring
1. Load Check Valve
2. Spring
3. Cover
4. Screw
5. Spring Holder
6. Spring
7. Cap Screw
8. O-ring
9. O-ring
10. O-ring
1. Load Check Valve
2. Spring
3. Cover
4. Screw
5. Spring Holder
6. Spring
7. Cap Screw
8. O-ring
9. O-ring
10. O-ring

Takeuchi TL150 Specifications

General

Travel Speed - High	11.2 mph (18 km/h)
Max Travel Speed	12.4 km/h
Width	1880 mm
Height	2320 mm
Lift Height	10.5 ft (3.2 m)
