Takeuchi TL150 Workshop Manual

III-34
MACHINE CONFIGURATIONCONTROL SYSTEM
1. Right Pilot Valve
2. Left Pilot Valve
3. Control Valve
4. Control Valve (Sub)
5. Solenoid Valve
6. HST Pump
7. Hydraulic Tank
8. Pilot Valve (Auxiliary)
9. Shuttle Valve
CONTROL SYSTEM
CONSTRUCTION
Hydraulic Pilot Unit (1/2)
zTable of Connectionsz
11
㲗
Pa2 3
12
㲗
Pb1 3
13
㲗
Pb2 3
14
㲗
Pa1 3
1P
㲗
11 4
1T
㲗
T2 5
21
㲗
X1 6
22
㲗
X11 6
23
㲗
X2 6
24
㲗
X12 6
2P
㲗
24
2T
㲗
T4 7


Takeuchi TL150 Specifications

General

Travel Speed - High	11.2 mph (18 km/h)
Max Travel Speed	12.4 km/h
Width	1880 mm
Height	2320 mm
Lift Height	10.5 ft (3.2 m)
