MACHINE CONFIGURATIONCONTROL SYSTEM
1. Right Pilot Valve
2. Left Pilot Valve
3. Control Valve
4. Control Valve (Sub)
5. Solenoid Valve
6. HST Pump
7. Hydraulic Tank
8. Pilot Valve (Auxiliary)
9. Shuttle Valve
Hydraulic Pilot Unit (2/2)
zTable of Connectionsz
5A
㲗
B9
5B
㲗
Pb32 3
5P
㲗
12 4
5T1
㲗
T5 7
81
㲗
Pb31 3
82
㲗
A9
8P
㲗
13 4
8T
㲗
T2 4
9C
㲗
Pa3 3
