II-6
SPECIFICATIONSSPECIFICATIONS TABLES
SPECIFICATIONS TABLES
SPECIFICATIONS
Type Canopy
Standard Bucket Capacity
Rated Capacity m
3
0.579
Struck Capacity m
3
0.426
Machine Mass (not including operator) kg 5485
Dimensions
Overall Lenght: with bucket mm 3985
without bucket mm 3135
Overall Width: with bucket mm 1960
without bucket mm 1860
Overall Height mm 2350
Minimum Ground Clearance mm 355
Front Clearance Radius: with bucket mm 2435
without bucket mm 1560
Rear Clearance Radius mm 1755
Overall Width of Crawler mm 1860
Overall Length of Crawler mm 2150
Bucket Width mm 1960
Angle of Departure
degree
31
Working Range
Maximum Lift Height to Bucket Pin mm 3210
Maximum Dumping Height mm 2440
Maximum Dump Angle Fully Raised
degree
39
Maximum Bucket Rollback at Ground Level
degree
31
Reach Fully Raised mm 1005
Performance
Breakout Force kN 38.5
Travel Speed 1st / 2nd km/h 5.8 / 8.3
Gradeability
degree
30
Ground Pressure kPa 39.0
Tipping Load kg 3300
Cycle Time
Raise-Full Load (Lift Arm) Sec. 4.8
Lower-No Load (Lift Arm) Sec. 3.1
Dump-Full Load (Bucket) Sec. 3.3
Curl-Full Load (Bucket) Sec. 2.4
