IV-81
HYDRAULIC UNITSPILOT VALVE
1. Casing
2. Cover
3. Plug
4. Seal
5. O-ring
6. Push Rod
7. Shim
8. Spool
PILOT VALVE (AUXILIARY)
CONSTRUCTION
L3D350
16
6
4
3
2
5
9
12
11
7
10
8
1
13
15
14
9. Spring Seat
10. Washer
11. Spring
12. Spring
13. Shaft
14. Bushing
15. Cam
16. Ball
