Takeuchi TL150 - Radiator (High Flow)

III-6
MACHINE CONFIGURATIONDRIVE SYSTEM
Radiator (High Flow)
Serial No. 21501587~
A: 4.9 N·m
B:
39.2 N·m
1. Radiator
2. Radiator Hose (Upper)
3. Radiator Hose (Lower)
4. Sub Tank
5. Sensor
6. Drain Valve
7. Drain Hose
8. Drain Hose
9. Hose
10. Joint
11. O-Ring
