II-3
SPECIFICATIONS
NAMES OF COMPONENTS
1. Lift Arm
2. Control Valve
3. Hydraulic Tank
4. Canopy
5. Safety Bar
6. Pilot Valve (L. H.)
7. Pilot Valve (R. H.)
8. HST Pump
9. Bucket Cylinder
10. Fuel Tank
11. Arm Cylinder
12. Travel Motor
13. Track Roller
14. Track
15. Idler
16. Quick-Hitch
17. Bucket
18. Control Valve (Sub)
19. Self-Level Valve
T7B001
17
16
10
15
14
13
18
8
11
19
12
3
2
4
5
1
7
6
9
