Takeuchi TL150 Workshop Manual

II-14
SPECIFICATIONS
SERVICE STANDARDS
Track Roller C
Unit: mm
Code Item Designated Standard
Servicing
Procedure
Basic Dimension Allowable Value
Replace
A Tread Outer Diameter 300 292
B Width of Tread 36.5 40.5
Basic
Dimension
Allowable Tolerance
Standard
Fit
Allowable
Fit
Shaft Hole
C
Shaft and Bearing Bore
Diameter Interference
40
0
-0.016
0
-0.012
0.016

0.012

±
D
Roller and Bearing Outer
Diameter Interference
68
0
-0.016
-0.014
-0.033
0.002

0.033

±
Standard Value Allowable Value
Shaft End Play 0.7 1.2
*: Maximum clearance **: Maximum interference




Takeuchi TL150 Specifications

General

Travel Speed - High	11.2 mph (18 km/h)
Max Travel Speed	12.4 km/h
Width	1880 mm
Height	2320 mm
Lift Height	10.5 ft (3.2 m)
