Takeuchi TL150 Workshop Manual

II-8
SPECIFICATIONSSPECIFICATIONS TABLES
SPECIFICATIONS OF DEVICES
Engine
Model Yanmar 4TNV106T-XTBL
Type
4-Cycle, vertical, water-cooled, in-line, 4-cylinder diesel engine
Number of Cylinders-Bore × Stroke mm 4-106 × 125
Total Displacement mL 4412
Compression Ratio 18.0
Performance
Rated Output kW/min
-1
72.0/2200
Maximum Torque N·m/min
-1
361.6~394.0/1400 ±100
Maximum No-load R.P.M. min
-1
2380 ±25
Minimum No-load R.P.M. min
-1
1150 ±25
Specific Fuel Consumption g/kW·h 252 or less
Starter V–kW 12–3.0
Generator V–kW 12–0.72
Battery V–A·h 12–92
HST Pump
Model PVM4141
Type Variable displacement type double axial piston
Displacement cm
3
/rev 41.0 + 41.0
Delivery L/min 90.2 + 90.2
Relief Valve Pressure Setting MPa 34.5
Charge Relief Valve Pressure Setting MPa 2.26 ±0.02
Gear Pump
Model SD1A4018E2H1-R211M
Type
Tandem gear
40.3 + 18.3
Displacement cm
3
/rev
Delivery L/min 88.7 + 40.3
Gear Pump (High Flow)
Model KFP 2223ASFSX
Type Gear
Displacement cm
3
/rev 22.9
Delivery L/min 62
Control Valve
Model 07813-00010
Number of Circuits 3
Main Relief Valve Pressure Setting MPa@L/min 20.6 @88
Port Relief Valve Pressure Setting MPa@L/min 23.1 @88
Control Valve (High Flow)
Model 07930-0000A
Relief Valve Pressure Setting
MPa@L/min 20.6 @60
Control Valve (Sub)
Model 07903-0000
Rated Flow L/min 41.6
Relief Valve Pressure Setting
MPa@L/min 3.3 @40

Takeuchi TL150 Specifications

General

Travel Speed - High	11.2 mph (18 km/h)
Max Travel Speed	12.4 km/h
Width	1880 mm
Height	2320 mm
Lift Height	10.5 ft (3.2 m)
