If only two feedback signals are used, the feedback that is not to be used
must be set to
No Function
in par. 20-00 Feedback 1 Source,
par. 20-03
Feedback 2 Source or par. 20-06 Feedback 3 Source. Note that
each setpoint reference will be the sum of its respective parameter value
(par. 20-21
Setpoint 1, par. 20-22 Setpoint 2 and par. 20-23 Setpoint 3) and
any other references that are enabled (see parameter group 3-1*).
Any unused feedback must be set to “No function” in its Feedback Source parameter: Par. 20-00
Feedback 1 Source,
par. 20-03
Feedback 2 Source or par. 20-06 Feedback 3 Source.
The feedback resulting from the function selected in par. 20-20
Feedback Function will be used by the PID Con-
troller to control the output frequency of the frequency converter. This feedback can also be shown on the
frequency converter’s display, be used to control a frequency converter's analog output, and be transmitted
over various serial communication protocols.
The frequency converter can be configured to handle multi zone applications. Two different multi zone appli-
cations are supported:
• Multi zone, single setpoint
• Multi zone, multi setpoint
How to program the Frequency Converter
BAS-SVX19C-EN 6-49
