1536 An exception in the Application Orienta-
ted Control is registered. Debug informa-
tion written in keypad
1792 DSP watchdog is active. Debugging of
power part data Motor Orientated Control
data not transferred correctly
2049 Power data restarted
2064-2
072
H081x: option in slot x has restarted
2080-2
088
H082x: option in slot x has issued a pow-
erup-wait
2096-2
104
H083x: option in slot x has issued a legal
powerup-wait
2304 Could not read any data from power EE-
PROM
2305 Missing SW version from power unit
2314 Missing power unit data from power unit
2315 Missing SW version from power unit
2316 Missing io_statepage from power unit
2324 Power card configuration is determined
to be incorrect at power up
2330 Power size information between the pow-
er cards does not match
2561 No communication from DSP to ATACD
2562 No communication from ATACD to DSP
(state running)
2816 Stack overflow Control board module
2817 Scheduler slow tasks
2818 Fast tasks
2819 Parameter thread
2820 keypad Stack overflow
2821 Serial port overflow
2822 USB port overflow
2836 cfListMempool to small
3072-5
122
Parameter value is outside its limits
5123 Option in slot A: Hardware incompatible
with Control board hardware
5124 Option in slot B: Hardware incompatible
with Control board hardware
5125 Option in slot C0: Hardware incompatible
with Control board hardware
5126 Option in slot C1: Hardware incompatible
with Control board hardware
5376-6
231
Out of memory
ALARM 39, Heatsink sensor
No feedback from the heatsink temperature sensor.
The signal from the IGBT thermal sensor is not avail-
able on the power card. The problem could be on the
power card, on the gate drive card, or the ribbon ca-
ble between the power card and gate drive card.
WARNING 40, Overload of Digital Output Ter-
minal 27
Check the load connected to terminal 27 or remove
short-circuit connection. Check par. 5-01
Terminal 27
Mode.
WARNING 41, Overload of Digital Output Ter-
minal 29
Check the load connected to terminal 29 or remove
short-circuit connection. Check par. 5-02
Terminal 29
Mode.
WARNING 42, Overload of Digital Output on
X30/6 or Overload of Digital Output on X30/7
For X30/6, check the load connected to X30/6 or re-
move short-circuit connection. Check par. 5-32
Term
X30/6 Digi Out (MCB 101).
For X30/7, check the load connected to X30/7 or re-
move short-circuit connection. Check par. 5-33
Term
X30/7 Digi Out (MCB 101).
ALARM 46, Power card supply
The supply on the power card is out of range.
There are three power supplies generated by the
switch mode power supply (SMPS) on the power
card: 24 V, 5V, +/- 18V. When powered with three
phase mains voltage, all three supplied are moni-
tored.
WARNING 47, 24 V supply low
The 24 Vdc is measured on the control card.
WARNING 48, 1.8 V supply low
The 1.8 Vdc supply used on the control card is outside
of allowable limits. The power supply is measured on
the control card.
WARNING 49, Speed limit
When the speed is not within the specified range in
par. 4-11 and par. 4-13. the drive will show a warning.
When the speed is below the specified limit in
par. 1-86
Trip Speed Low [RPM] (except when starting
or stopping) the drive will trip.
ALARM 50, AMA calibration failed
Contact your Trane supplier.
ALARM 51, AMA check Unom and Inom
The setting of motor voltage, motor current, and mo-
tor power is presumably wrong. Check the settings.
ALARM 52, AMA low Inom
The motor current is too low. Check the settings.
Troubleshooting
BAS-SVX19C-EN 7-11
