- Cables, wiring harness -
14.01 Replacing motorstop
cable
14.01.01 Detaching motorstop
cable
- Remove motorstop control bar
(see section 03.02.01)
- Remove engine
(see section 12.05.01)
14.01.02 Attaching motorstop
cable
- Install motorstop control bar
(see section 03.02.02)
- Install engine
(see section 12.05.02)
14.03 Replacing wheel drive
cable
14.03.01 Detaching wheel drive
cable
- Dismantle outside left housing half
(see section 02.05.05)
- Remove rear axle (with gearbox)
(see section 04.02.01)
14.03.02 Attaching wheel drive
cable
- Install rear axle (with gearbox)
(see section 04.02.04)
- Assemble outside left housing half
(see section 02.05.06)
14.02 Replacing blade
clutch / Quick-Start
cable
14.02.01 Detaching blade
clutch / Quick-Start
cable
- Remove outside right housing half
(see section 02.03.02)
- Detach blade clutch / Quick-Start
cable from lever.
Blade clutch:
- Remove clutch flange
(see section 11.10.01)
Quick-Start:
- Remove engine
(see section 12.05.01)
Blade clutch:
- Install clutch flange
(see section 11.10.03)
Quick-Start:
- Install engine
(see section 12.05.02)
14.02.02 Attaching blade clutch /
Quick-Start cable
- Attach blade clutch / Quick-Start
cable to lever.
- Attach outside right housing half
(see section 02.04.01)
14. Cables, wiring harness
110
