Viking MB 650 - Installing Bracket; Removing Throttle Lever; Replacing Throttle Lever

RA_6360_6375_01 - EN33
- Control bars and levers -
• Detach handle 1 from lever.
1
• Unclip throttle lever 1 from housing
half.
1
03.09 Replacing throttle lever
03.09.01 Removing throttle lever
MB 650.0 TK
- Remove inside right housing half
(see section 02.03.01)
Models with Vario / three-speed
gearbox
• Remove spring washers 1 (2x).
Models with Vario / three-speed
gearbox
- Remove Vario / three-speed lever
(see section 03.07.01)
1
1
03.08.02 Installing bracket
• Clip bracket 1 into housing half.
- Install Vario / three-speed lever
(see section 03.07.02)
1
• Insert spring washers 1 (2x) (ensure
opposing position).
1
1
1
1
