Viking MB 650 - Installing Vario V-Belt Pulley and Adjusting Element

RA_6360_6375_01 - EN
- Gearbox -
06.02.04 Installing Vario V-belt
pulley and adjusting
element
• Fit washer 1 and V-belt pulley 2 onto
gearbox 3.
• Drive in roll pin 1.
• Remove Vario adjusting element 1
from gearbox 2.
• Fit Vario adjusting element 1 onto
gearbox 2.
• Drive out roll pin 1.
• Remove V-belt pulley 1 with washer
2 from gearbox 3.
67
