RA_6360_6375_01 - EN 46
- Chassis -
04.03.03 Installing front wheel
cap
• Position wheel cap 1 so that
recesses 2 on inside are aligned
with high spokes 3 of wheel.
Push the wheel cap 1 firmly onto
wheel 4.
1
4
2
3
3
04.03.04 Installing rear wheel
cap
• Position wheel cap 1 and push
under rubber lip of tyre.
1
04.04 Replacing wheel
• Remove bolt 1.
04.04.01 Removing front wheel
1
• Remove clamping ring 1.
1
- Remove front wheel cap
(see section 04.03.01)
- Detach clamping ring from wheel
hub by striking it lightly (rubber
mallet).
up to serial number 4 31 427 503
 04.04.01 (A)
