Viking MB 650 - Replacing Left;Right Protection Bumpers; Removing Left;Right Protection Bumpers; Installing Left;Right Protection Bumpers; Replacing Guiding Plate

RA_6360_6375_01 - EN
- Housing -
• Remove screws 1.
1
1
1
• Remove protection bumper 1.
1
05.10 Replacing left/right
protection bumpers
05.10.01 Removing left/right
protection bumpers
• Remove screws 1.
1
1
• Remove guiding plate 1.
1
05.11 Replacing guiding
plate
05.11.01 Removing guiding
plate
• Engage protection bumper 1
in guides and tighten screws 2
(1-2 Nm).
1
2
2
2
05.10.02 Installing left/right
protection bumpers
