Viking MB 650 - Removing Bracket; Replacing Bracket

RA_6360_6375_01 - EN 32
- Control bars and levers -
• Attach cable 1 in bracket.
1
• Fit handle 1
1
• Attach cable 1 to lever 2 (large bore
on left, see Fig.).
1
2
2
1
- Attach inside right housing half
(see section 02.04.02)
03.08 Replacing bracket
03.08.01 Removing bracket
• Remove spring washers 1 (2x).
- Remove Vario / three-speed lever
(see section 03.07.01 03.07.01)
1
1
• Unclip bracket 1 from housing half.
1
