Viking MB 650 - Assembling Detent Segment; Dismantling Detent Segment

RA_6360_6375_01 - EN
- Height adjustment -
• Remove nuts 1, remove screws 2
(bushing 3 and sheet metal
reinforcement 4 are not individual
spare parts).
• Remove screws 1 (bushing 2 is not
an individual spare part).
07.04.02 Dismantling detent
segment
• Tighten screws 1 (1 Nm), (bushing 2
is not an individual spare part).
07.04.03 Assembling detent
segment
from serial number 4 30 856 348
up to serial number 4 30 856 347
up to serial number 4 30 856 347
• Remove nut 1.
1
• Remove detent segment 2 with
bolt 1.
1
2
07.04 Replacing detent
segment
07.04.01 Removing detent
segment
- Remove detent segment tension
spring
(see section 07.02.01)
• Tighten screws 1, 2, tighten nuts 3
(1 Nm), (bushing 4 and sheet metal
reinforcement 5 are not individual
spare parts).
from serial number 4 30 856 348
77
