Viking MB 650 - Assembling Rear Axle; Removing Bearing and Washer; Inserting Washer and Bearing

RA_6360_6375_01 - EN 40
- Chassis -
• Remove bearing 1 and washer 2
from bushing (right side).
• Remove gearbox 1 from axle 2 in
direction of arrow.
• Insert washer 1 and bearing 2 into
axle bushing 3 (left side).
• Remove bearing 1 and washer 2
from axle bushing (left side).
04.02.03 Assembling rear axle
