- Mowing blade -
09.01.02 Installing mowing blade
Models without blade clutch
• Attach mowing blade 1.
• Tighten blade fastening screw 3 with spring washer 2 (60-65 Nm, Loctite 243).
1
2
3
Models with blade clutch
• Attach mowing blade 1.
• Tighten blade fastening screw 3 with guard plate 2 (45-55 Nm).
3
3
2
1
Note:
Ensure correct position of spring washer 2 (conical).
83
