Viking MB 650 - Installing Left Drive Pinion; Installing Right Drive Pinion; Removing Right Freewheel Wedge; Replacing Freewheel Wedge

- Chassis -
52 RA_6360_6375_01 - EN
• Unclip right axle bracket 1.
04.08 Replacing freewheel
wedge
04.08.01 Removing right
freewheel wedge
- Remove right drive pinion
(see section 04.07.01)
• Fit pinion 1
(Part No. 6105 704 7410), fit
washer 2 and install retaining ring 3.
04.07.04 Installing left drive
pinion
- Install rear wheel cover
(see section 04.06.02)
• Fit pinion 1
(Part No. 6105 704 7400), fit
washer 2 and install retaining ring 3.
04.07.03 Installing right drive
pinion
- Install rear wheel cover
(see section 04.06.02)
• Remove retaining ring 1, washer 2
and pinion 3.
