Viking MB 650 - Removing Rear Wheel

RA_6360_6375_01 - EN47
• Remove nut 1.
1
• Remove nut 1.
1
- Chassis -
• Remove wheel 1.
1
04.04.02 Removing rear wheel
- Remove rear wheel cap
(see section 04.03.02)
• Remove bolt 1.
1
- Detach clamping ring from wheel
hub by striking lightly (rubber
mallet).
• Remove clamping ring 1.
1
• Remove wheel 1.
1
up to serial number 4 31 427 503
from serial number 4 31 427 504from serial number 4 31 427 504
 04.04.01 (A)
04.04.01 (A)
 04.04.02 (A)
04.04.02 (A)
 04.04.02 (A)
