RA_6360_6375_01 - EN 44
- Chassis -
• Clip in axle bracket 1 (left / right).
Models with single-speed
gearbox
• Attach wheel drive cable 1 at
gearbox 2.
Models with Vario gearbox
• Attach wheel drive cable 1 and
speed control cable 2 at gearbox 3
(tip gearbox backwards for this
purpose).
Models with three-speed gearbox
• Attach three-speed cable 1 at
gearbox 2.
Models with three-speed gearbox
- Install cable support
(see section 06.06.02;
Do not attach housing cover
assembly)
