TP 39217202 XC70(08-) & S80(07-) 2012 216
74/301
34-pin black
No. Engine harness Engine compartment harness
1
4/46A:25 Engine control module (ECM),
2.0l Diesel, MAN
4/46B:54 Engine control module (ECM),
4-Cyl. Turbo & 5-Cyl. MAN
73/3014 Branching point
73/3139 Branching point
BU-BK
73/3021 Branching point
BU-BK
24/46A:17Engine Control Module (ECM),
4-Cyl. Diesel, MAN
4/46B:41 Engine control module (ECM),
4-Cyl. & 5-Cyl. MAN
73/3015 Branching point
73/3140 Branching point
GN-BK
73/3022 Branching point
GN-BK
34/46B:25Engine control module (ECM),
1.6l Diesel
4/46C:30 Engine control module (ECM),
2.0l Diesel
BN-WH
4/56C1:3 Central Electronic Module
(CEM)
BN-WH
4-
-
-
-
5-
-
-
-
64/46B:35Engine Control Module (ECM),
4-Cyl. T, 5 & 6-Cyl.
4/46B:31 Engine control module (ECM),
1.6l Diesel
4/46B:46 Engine Control Module (ECM),
5-Cyl. Diesel
WH
74/504:1 Connector
WH
74/46B:21Engine control module (ECM),
5-Cyl. Diesel
4/46B:45 Engine control module (ECM),
2.0l Diesel
4/46B:34 Engine Control Module (ECM),
4-Cyl. T, 5 & 6-Cyl.
73/3084 Branching point
BK-WH
74/504:2 Connector
BK-WH
8-
-
-
-
94/28A:13Transmission Control Module
(TCM)
4/28A:1 Transmission Control Module
(TCM), MPS6
GN-OG
74/411:9 Connector
GN-OG
10 4/46A:30 Engine control module (ECM),
2.0l Diesel
4/46B:14 Engine Control Module (ECM),
4-Cyl. T, 5 & 6-Cyl.
4/46B:23 Engine Control Module (ECM),
5-Cyl. Diesel
VT-OG
4/56C1:6 Central Electronic Module
(CEM)
VT-OG
continues
Connectors
74/301:1-10
