TP 39217202 XC70(08-) & S80(07-) 2012 217
74/301
34-pin black
No. Engine harness Engine compartment harness
11 4/28A:7 Transmission Control Module
(TCM)
4/28A:17 Transmission Control Module
(TCM), MPS6
BN-VT
74/411:10 Connector
BN-VT
12 3/10:1 Reversing light contact, Man
BU
4/56C1:29 Central Electronic Module
(CEM)
BU
13 4/46C:26 Engine control module (ECM),
2.0l Diesel
4/46B:51 Engine Control Module (ECM),
4-Cyl. T, 5 & 6-Cyl.
4/46B:34 Engine Control Module (ECM),
5-Cyl. Diesel
GN-BN
7/8:2 Pressure sensor, climate
control system
GN-BN
14 4/46C:14 Engine control module (ECM),
2.0l Diesel
4/46B:53 Engine Control Module (ECM),
5 & 6-Cyl.
4/46B:8 Engine Control Module (ECM),
5-Cyl. Diesel
4/46B:37 Engine Control Module (ECM),
4-Cyl. T
73/3084 Branching point
BN
7/8:1 Pressure sensor, climate
control system
BN
15 4/46C:2 Engine control module (ECM),
2.0l Diesel
4/46B:31 Engine Control Module (ECM),
4-Cyl. T, 5 &
6-Cyl.
4/46B:11 Engine Control Module (ECM),
5-Cyl. Diesel
GY-BN
7/8:3 Pressure sensor, climate
control system
GY-BN
16 2/14:1 Relay, glow plug system.
4-Cyl. T
2/133:1 Relay vacuum pump, 5-Cyl.
Turbo
GN-OG
11B/22:2 Fuse, Distribution box in
engine compartment
11B/19:2 Fuse, Distribution box in
engine compartment
GN-OG
17 11B/41:2 Fuse, distribution box in engine
compartment, Gasoline
73/3131 Branching point, Diesel
BU
74/504:21 Connector
BU
18 4/46C:43 Engine control module (ECM),
2.0l Diesel
4/46B:30 Engine Control Module (ECM),
4-Cyl. T, 5 & 6-Cyl.
VT-BN
4/56C1:5 Central Electronic Module
(CEM)
VT-BN
continues
Connectors
74/301:11-18
