Volvo XC70 2012 - Page 218

TP 39217202 XC70(08-) & S80(07-) 2012 218
74/301
34-pin black
No. Engine harness Engine compartment harness
19 4/46C:29 Engine control module (ECM),
2.0l Diesel
4/46B:26 Engine Control Module (ECM),
4-Cyl. T, 5 & 6-Cyl.
4/46B:30 Engine Control Module (ECM),
5-Cyl. Diesel
BU-WH
74/504:17 Connector
BU-WH
20 4/46C:42 Engine control module (ECM),
2.0l Diesel
4/46B:13 Engine Control Module (ECM),
4-Cyl. T, 5 & 6-Cyl.
4/46B:25 Engine Control Module (ECM),
5-Cyl. Diesel
GY-BN
74/504:42 Connector
GY-BN
21 4/28A:16 Transmission Control Module
(TCM)
4/28A:13 Transmission Control Module
(TCM), MPS6
BU-GY
74/411:11 Connector
BU-GY
22 4/46C:38 Engine control module (ECM),
2.0l Diesel
4/46B:17 Engine Control Module (ECM),
4-Cyl. T, 5-Cyl. T, 6-Cyl
4/46B:53 Engine Control Module (ECM),
5-Cyl. Diesel
BU-WH
4/56C1:41 Central Electronic Module
(CEM)
BU-WH
23 -
-
-
-
24 4/46B:45 Engine Control Module (ECM),
6-Cyl.
GN-OG
74/504:38 Connector
GN-OG
25 -
-
-
-
26 -
-
-
-
27 -
-
-
-
28 -
-
-
-
29 4/46B:21 Engine Control Module (ECM),
5 & 6-Cyl.
4/46B:45 Engine Control Module (ECM),
4-Cyl. T
YE-OG
74/504:18 Connector
YE-OG
30 -
-
-
-
31 4/46B:46 Engine Control Module (ECM),
6-Cyl.
BU-GY
74/504:39 Connector
BU-GY
32 4/46A:19 Engine control module (ECM),
2.0l Diesel, Man
4/46B:15 Engine Control Module (ECM),
4-Cyl. T, 5 & 6-Cyl. Man
73/3064 Branching point, Auto
VT-BN
11B/20:2 Fuse, Distribution box in
engine compartment
VT-BN
33 4/46B:23 Engine Control Module (ECM),
6-Cyl.
VT-OG
74/504:37 Connector
VT-OG
34 -
-
-
-
Connectors
74/301:19-34
