Volvo XC70 2012 - Page 219

TP 39217202 XC70(08-) & S80(07-) 2012 219
74/302 4-Cyl.
1-pin black
No. Engine harness Harness Starter motor
12/35:5 Relay, starter motor
BU-WH
6/25C2:1 starter motor
BU-WH
74/304
2-pin black
No. Engine compartment harness Harness washer nozzle
111B/21:2Fuse, Distribution box in engine
compartment
BU-GY
73/3040 Branching point
BU-GY
273/3033Branching point
BK-OG
73/3037 Branching point
BK-OG
74/307 4-Cyl. Diesel
4-pin black
No. Engine harness Glow plug
173/3081Branching point
VT
20/22:1 Glow plug
VT
273/3081Branching point
VT
20/23:1 Glow plug
VT
373/3081Branching point
VT
20/24:1 Glow plug
VT
437/3081Branching point
VT
20/25:1 Glow plug
VT
74/309
12-pin gray
No. Engine compartment harness Harness bumper, front
1-
-
-
-
2-
-
-
-
3-
-
-
-
474/519:12Connector
VT-GY
73/3046 Branching point
VT-GY
574/519:13Connector
BU-GN
7/204:2 Front parking assistance
sensor
BU-GN
674/519:14Connector
YE-OG
73/3047 Branching point
YE-OG
7-
-
-
-
8-
-
-
-
9-
-
-
-
10 74/519:15 Connector
BU-BK
7/205:2 Front parking assistance
sensor
BU-BK
11 74/519:16 Connector
BU-GY
7/206:2 Front parking assistance
sensor
BU-GY
12 74/519:17 Connector
BU-OG
7/207:2 Front parking assistance
sensor
BU-OG
Connectors
74/302 - 74/309
