TP 39217202 XC70(08-) & S80(07-) 2012 220
74/310 4-Cyl. 1.6l Turbo
8-pin black
No. Engine harness Engine harness
18/6:2 Injection valves
YE-BU
4/46A:3 Engine Control Module (ECM)
YE-BU
28/6:1 Injection valves
GN-BU
4/46A:77 Engine Control Module (ECM)
GN-BU
38/7:2 Injection valves
BU-OG
4/46A:25 Engine Control Module (ECM)
BU-OG
48/7:1 Injection valves
GY-YE
4/46A:52 Engine Control Module (ECM)
GY-YE
58/8:2 Injection valves
GN-VT
4/46A:26 Engine Control Module (ECM)
GN-VT
68/8:1 Injection valves
VT-GY
4/46A:76 Engine Control Module (ECM)
VT-GY
78/9:2 Injection valves
BU-OG
4/46A:27 Engine Control Module (ECM)
BU-OG
88/9:1 Injection valves
YE-OG
4/46A:53 Engine Control Module (ECM)
YE-OG
74/310 4-Cyl. 2.0l Turbo
16-pin black
No. Engine harness Engine harness
18/6:1 Injection valves
GN-BU
4/46A:77 Engine Control Module (ECM)
GN-BU
27/23:2 Rear knock sensor
BN-BU
4/46A:61 Engine Control Module (ECM)
BN-BU
37/24:2 Front knock sensor
VT-OG
4/46A:60 Engine Control Module (ECM)
VT-OG
48/7:1 Injection valves
GY-YE
4/46A:52 Engine Control Module (ECM)
GY-YE
58/8:1 Injection valves
VT-GY
4/46A:76 Engine Control Module (ECM)
VT-GY
68/9:1 Injection valves
YE-OG
4/46A:53 Engine Control Module (ECM)
YE-OG
77/23:1 Rear knock sensor
BN-GN
4/46A:85 Engine Control Module (ECM)
BN-GN
87/24:1 Front knock sensor
WH-BN
4/46A:84 Engine Control Module (ECM)
WH-BN
98/6:2 Injection valves
YE-BU
4/46A:3 Engine Control Module (ECM)
YE-BU
10 -
-
-
-
11 -
-
-
-
12 8/7:2 Injection valves
BU-OG
4/46A:25 Engine Control Module (ECM)
BU-OG
13 8/8:2 Injection valves
GN-VT
4/46A:26 Engine Control Module (ECM)
GN-VT
14 8/9:2 Injection valves
BU
4/46A:27 Engine Control Module (ECM)
BU
15 -
-
-
-
16 -
-
-
-
74/313
1-pin black
No. Harness battery monitoring sensor (BMS) Engine compartment harness
17/240:2Battery monitoring sensor
(BMS)
GN-BK
4/56C1:49 Central Electronic Module
(CEM)
GN-BK
Connectors
74/310 - 74/313
