Volvo XC70 2012 - Page 221

TP 39217202 XC70(08-) & S80(07-) 2012 221
74/318
2-pin black
No. Engine harness Engine compartment harness
17/25:1 Impulse sensor
GY-VT
4/46A:39 Engine Control Module
(ECM)
GY-VT
27/25:2 Impulse sensor
GN-BN
4/46A:7 Engine Control Module
(ECM)
GN-BN
74/401
22-pin gray
No. Center console harness Dashboard harness
14/6C1:12Climate Control Module (CCM)
WH-GN
74/417:3 Connector
WH-GN
24/6C1:7Climate Control Module (CCM)
BN-VT
73/4010 Branching point
BN-VT
34/6C1:14Climate Control Module (CCM)
YE-VT
74/417:6 Connector
YE-VT
44/6C1:5Climate Control Module (CCM)
VT-BN
74/417:5 Connector
VT-BN
54/6C1:13Climate Control Module (CCM)
WH-GN
74/417:7 Connector
WH-GN
63/281C1:6Infotainment Control Module
(ICM)
GN-OG
3/130C1:6 Steering Wheel Module
(SWM)
GN-OG
74/6C1:1Climate Control Module (CCM)
RD
4/56C3:73 Central Electronic Module
(CEM)
RD
84/6C1:2Climate Control Module (CCM)
VT-BK
4/31:2 Passenger compartment fan
control module
VT-BK
93/281C1:2Infotainment Control Module
(ICM)
4/6C1:10 Climate Control Module (CCM)
GY-OG
73/4001 Branching point
73/4034 Branching point
74/409:19 Connector
GY-OG
10 3/281C1:3 Infotainment Control Module
(ICM)
4/6C1:8 Climate Control Module (CCM)
VT-OG
73/4002 Branching point
73/4035 Branching point
74/409:20 Connector
VT-OG
11 -
-
-
-
12 -
-
-
-
13 -
-
-
-
14 -
-
-
-
15 -
-
-
-
16 -
-
-
-
17 -
-
-
-
18 -
-
-
-
19 -
-
-
-
20 -
-
-
-
21 3/281C1:1 Infotainment Control Module
(ICM)
GY-YE
16/1C2:1 Integrated Audio Module
(IAM)
YE-RD
22 73/4018 Branching point
BK
73/4016 Branching point
BK
Connectors
74/318 - 74/401
