TP 39217202 XC70(08-) & S80(07-) 2012 222
74/402
2-pin black
No. Center console harness Dashboard harness
13/281C2:1Infotainment Control Module
(ICM)
OG
16/1C4:2 Integrated Audio Module (IAM)
OG
23/281C2:2Infotainment Control Module
(ICM)
OG
16/1C4:1 Integrated Audio Module (IAM)
16/60C4:1 Phone Module (PHM)
16/147C2:1 Bluetooth Phone Module (BPM)
OG
74/403
22-pin gray
No. Dashboard harness Tunnel harness
116/1C2:10Integrated Audio Module
(IAM)
BN
16/123:4 Auxiliary equipment input (AUX)
16/123.2:5 Auxiliary equipment input (AUX)
BN
216/1C2:11Integrated Audio Module
(IAM)
GN
16/123:2 Auxiliary equipment input (AUX)
16/123.2:7 Auxiliary equipment input (AUX)
GN
316/1C2:12Integrated Audio Module
(IAM)
WH
16/123:1 Auxiliary equipment input (AUX)
16/123.2:6 Auxiliary equipment input (AUX)
WH
416/1C2:8Integrated Audio Module
(IAM)
-
-
-
5-
-
-
-
64/56C3:67Central Electronic Module
(CEM)
BU-RD
3/65:1 Switch, heated rear seat
BU-RD
74/56C3:69Central Electronic Module
(CEM)
BU-RD
16/181:13 Rear headphone sockets
10/72:1 Front ashtray lighting
74/1502:1 Connector
BU-RD
874/411:9Connector
GN-RD
3/156A:3 Gear Selector Module (GSM)
GN-OG
974/411:11Connector
BU-GY
3/156A:1 Gear Selector Module (GSM)
BU-GY
10 -
-
-
-
11 -
-
-
-
12 16/60C1:18 Phone Module (PHM)
-
-
-
13 16/60C1:7 Phone Module (PHM)
GN-WH
-
-
14 16/60C1:8 Phone Module (PHM)
WH-BU
-
-
15 16/60C1:19 Phone Module (PHM)
WH-BN
-
-
16 16/60C1:20 Phone Module (PHM)
WH
-
-
17 -
-
-
-
18 -
-
-
-
19 -
-
-
-
20 4/56C3:38 Central Electronic Module
(CEM)
WH-BN
8/134:1 Solenoid, reverse interlock,
manual
WH-BN
21 4/56C3:65 Central Electronic Module
(CEM)
GY-YE
16/109A:4 DVD player/control module
GY-YE
22 74/411:10 Connector
BN-VT
3/156A:2 Gear Selector Module (GSM)
BN-VT
Connectors
74/402 - 74/403
