TP 39217202 XC70(08-) & S80(07-) 2012 224

74/407 Alternative 1

16-pin green

No. Dashboard harness Floor harness

116/1C1:12Integrated Audio Module (IAM)

GY-BK

74/507:23 Connector

GY-BK

316/1C1:7Integrated Audio Module (IAM)

YE-BK

74/508:23 Connector

YE-BK

416/1C1:9Integrated Audio Module (IAM)

GY-RD

74/509:4 Connector

GY-RD

516/1C1:10Integrated Audio Module (IAM)

YE-RD

74/510:4 Connector

YE-RD

916/1C1:6Integrated Audio Module (IAM)

GN-BK

74/507:22 Connector

GN-BK

10 -

11 16/1C1:1 Integrated Audio Module (IAM)

VT-BK

74/508:22 Connector

VT-BK

12 16/1C1:3 Integrated Audio Module (IAM)

GN-RD

74/509:3 Connector

GN-RD

13 16/1C1:4 Integrated Audio Module (IAM)

VT-RD

74/510:3 Connector

VT-RD

14 -

15 -

16 -

Connectors

74/407
