Volvo XC70 2012 - Page 225

TP 39217202 XC70(08-) & S80(07-) 2012 225
74/407 Alternative 2
16-pin green
No. Infotainment harness Floor harness
174/407B:1Connector
GY-BK
74/507:23 Connector
GY-BK
274/407B:2Connector
GY
74/409:10 Connector
GY
374/407B:3Connector
YE-BK
74/508:23 Connector
YE-BK
474/407B:4Connector
GY-RD
74/509:4 Connector
GY-RD
574/407B:5Connector
YE-RD
74/510:4 Connector
YE-RD
6-
-
-
-
7-
-
-
-
8-
-
-
-
974/407B:9Connector
GN-BK
74/507:22 Connector
GN-BK
10 74/407B:10 Connector
GN
74/409:9 Connector
GN
11 74/407B:11 Connector
VT-BK
74/508:22 Connector
VT-BK
12 74/407B:12 Connector
GN-RD
74/509:3 Connector
GN-RD
13 74/407B:13 Connector
VT-RD
74/510:3 Connector
VT-RD
14 -
-
-
-
15 -
-
-
-
16 -
-
-
-
74/407B
16-pin green
No. Infotainment harness Floor harness
116/105C1:1Audio module (AUD)
GY-BK
74/407:1 Connector
GY-BK
216/105C1:2Audio module (AUD)
GY
74/407:2 Connector
GY
316/105C1:3Audio module (AUD)
YE-BK
74/407:3 Connector
YE-BK
416/105C1:4Audio module (AUD)
GY-RD
74/407:4 Connector
GY-RD
516/105C1:5Audio module (AUD)
YE-RD
74/407:5 Connector
YE-RD
6-
-
-
-
7-
-
-
-
8-
-
-
-
916/105C1:9Audio module (AUD)
GN-BK
74/407:9 Connector
GN-BK
10 16/105C1:10 Audio module (AUD)
GN
74/407:10 Connector
GN
11 16/105C1:11 Audio module (AUD)
VT-BK
74/407:11 Connector
VT-BK
12 16/105C1:12 Audio module (AUD)
GN-RD
74/407:12 Connector
GN-RD
13 16/105C1:13 Audio module (AUD)
VT-RD
74/407:13 Connector
VT-RD
14 -
-
-
-
15 -
-
-
-
16 -
-
-
-
Connectors
74/407 - 74/407B
