TP 39217202 XC70(08-) & S80(07-) 2012 226
74/409
26-pin green
No. Dashboard harness Floor harness
110/18 Lamp housing, rear left
VT-GN
16/45C6:2 Portable navigation system
VT-GN
23/272:3Switch, parking brake
BU
4/115C1:20 Park Brake Module (PBM)
BU-WH
33/272:8Switch, parking brake
GN-WH
4/115C1:11 Park Brake Module (PBM)
GN-WH
43/272:7Switch, parking brake
WH-BN
4/115C1:18 Park Brake Module (PBM)
WH-BN
53/272:4Switch, parking brake
VT-GN
4/115C1:9 Park Brake Module (PBM)
VT-GN
63/272:6Switch, parking brake
WH-OG
4/115C1:19 Park Brake Module (PBM)
WH-OG
73/272:5Switch, parking brake
BN
4/115C1:10 Park Brake Module (PBM)
BN
8-
-
-
-
916/26:1Center dashboard speaker
GN
74/407:10 Connector
GN
10 16/26:2 Center dashboard speaker
GY
74/407:2 Connector
GY
11 -
--
12 -
--
13 16/1C2:2 Integrated Audio Module (IAM)
GN-VT
16/16C1:1 Window antenna amplifier
GN-VT
14 -
-
-
-
15 74/417:3 Connector
WH-GN
73/5021 Branching point
74/30:4 Connector, LHD
WH-GN
74/31:4 Connector, RHD
BN-VT
16 73/4010 Branching point
BN-VT
74/30:4 Connector, RHD
WH-GN
9/15A:2 Control module, RH rear
seat heater
74/31:4 Connector, LHD
BN-VT
17 11C/19:2 Fuse in distribution box
passenger compartment
BU-RD
16/60C1:5 Phone Module (PHM)
16/147C1:32 Bluetooth Phone Module
(BPM)
BU-RD
18 11C/21:2 Fuse in distribution box
passenger compartment
BU-GY
74/414:3 Connector
74/417:1 Connector
BU-GY
19 73/4034 Branching point
74/401:9 Connector
GY-OG
73/5005 Branching point
73/5009 Branching point
GY-OG
20 73/4035 Branching point
74/401:10 Connector
VT-OG
73/5006 Branching point
73/5010 Branching point
VT-OG
21 -
-
-
-
22 73/4038 Branching point
GN-BK
74/518:2 Connector
73/5016 Branching point
GN-BK
23 73/4037 Branching point
BU-BK
74/518:1 Connector
73/5015 Branching point
BU-BK
24 -
-
-
-
25 -
-
-
-
26 11C/18:2 Fuse in distribution box
passenger compartment
YE-RD
16/1C2:1 Integrated Audio Module
(IAM)
YE-RD
Connectors
74/409
