Volvo XC70 2012 - Page 227

TP 39217202 XC70(08-) & S80(07-) 2012 227
74/411
26-pin gray
No. Engine compartment harness Dashboard harness
111B/11:2Fuse, Distribution box in engine
compartment
YE-RD
73/4028 Branching point
YE-RD
2-
-
-
-
34/56C3:63Central Electronic Module
(CEM)
VT
7/203:1 Forward-aimed radar (FLR)
VT
47/203:18Forward-aimed radar (FLR)
BN-BU
4/80C1:8 Forward Sensing Module
(FSM)
BN-BU
57/203:9Forward-aimed radar (FLR)
GY-BU
4/80C1:9 Forward Sensing Module
(FSM)
GY-BU
610/1:8 Lamp housing, front left
10/2:8 Lamp housing, front right
BK
73/4017 Branching point, LHD
73/4016 Branching point
BK
7-
-
-
-
8-
-
-
-
974/301:9Connector
GN-OG
74/403:8 Connector
GN-RD
10 74/301:11 Connector
BN-VT
74/403:22 Connector
BN-VT
11 74/301:21 Connector
BU-GY
74/403:9 Connector
BU-GY
12 11B/23:2 Fuse, Distribution box in engine
compartment
RD-BK
3/111:1 Light Switch Module (LSM)
RD-BK
13 10/1:12 Lamp housing, front left
10/2:12 Lamp housing, front right
VT-GN
3/111:4 Light Switch Module (LSM)
VT-GN
14 -
-
-
-
15 -
-
-
-
16 -
-
-
-
17 -
-
-
-
18 -
-
-
-
19 -
-
-
-
20 -
-
-
-
21 7/178:1 Front impact sensor, right
WH-GN
4/9C2:50 Supplemental restraint
system module (SRS)
WH-GN
22 7/178:2 Front impact sensor, right
YE-RD
4/9C2:49 Supplemental restraint
system module (SRS)
YE-RD
23 7/179:1 Front impact sensor, left
WH-BU
4/9C2:75 Supplemental restraint
system module (SRS)
WH-BU
24 7/179:2 Front impact sensor, left
GY-BN
4/9C2:74 Supplemental restraint
system module (SRS)
GY-BN
25 11B/20:2 Fuse, Distribution box in engine
compartment
VT-BN
4/9C2:68 Supplemental restraint
system module (SRS)
VT-BN
26 -
-
-
-
Connector
74/411
