Volvo XC70 2012 - Page 228

TP 39217202 XC70(08-) & S80(07-) 2012 228
74/412
16-pin green
No. Dashboard harness Roof harness
116/1C2:4Integrated Audio Module (IAM)
WH
16/98:1 Microphone
WH
2-
-
-
-
34/119.2:1Remote Receiver Module
(RRX)
RD-BN
4/56C4:19 Central Electronic Module
(CEM)
RD-BN
416/60C1:14Phone Module (PHM)
-
3/267:2 Switch unit, telematics
-
516/60C1:3Phone Module (PHM)
BU-GY
3/267:3 Switch unit, telematics
BU-GY
64/9C2:70Supplemental restraint system
module (SRS)
GN-WH
3/117C1:3 Switch unit, ceiling light
GN-WH
74/80C1:1Forward Sensing Module (FSM)
GY-BK
9/39:1 Heating element camera
GY-BK
816/1C2:5Integrated Audio Module (IAM)
-
16/98:2 Microphone
-
94/80C1:14Forward Sensing Module (FSM)
BK
9/39:2 Heating element camera
BK
10 4/9C2:47 Supplemental restraint system
module (SRS)
GY-BU
3/117C1:2 Switch unit, ceiling light
GY-BU
11 16/60C1:15 Phone Module (PHM)
WH
3/267:1 Switch unit, telematics
WH
12 -
-
-
-
13 16/60C1:2 Phone Module (PHM)
GY-VT
3/267:6 Switch unit, telematics
GY-VT
14 16/60C1:1 Phone Module (PHM)
BN-GN
3/267:5 Switch unit, telematics
BN-GN
15 16/60C1:4 Phone Module (PHM)
YE-VT
3/267:4 Switch unit, telematics
YE-VT
16 16/60C1:13 Phone Module (PHM)
VT
3/267:7 Switch unit, telematics
VT
74/413
6-pin green
No. Dashboard harness Harness Start Control Module (SCU)
14/56C3:74Central Electronic Module
(CEM)
RD-VT
3/132:1 Start Control Module (SCU)
RD-VT
273/4016Branching point
BK
3/132:2 Start Control Module (SCU)
BK
34/56C3:50Central Electronic Module
(CEM)
GY
3/132:3 Start Control Module (SCU)
GY
4-
-
-
-
573/4027Branching point
BU
3/132:5 Start Control Module (SCU)
BU-WH
6-
-
-
-
Connector
74/412 - 74/413
