TP 39217202 XC70(08-) & S80(07-) 2012 229
74/414
4-pin gray
No. Dashboard harness Roof harness
14/56C3:75Central Electronic Module
(CEM)
RD-BN
4/33:1 Sunroof control module
RD-BN
273/4012Branching point
BK-WH
4/33:10 Sunroof Module (SRM)
73/4014 Branching point
BK-WH
374/409:18Connector
BU-GY
10/22C1:5 Ceiling light
73/4031 Branching point
BU-GY
410/22C1:7Ceiling light
73/4010 Branching point
GU-GY
74/409:18 Connector
BU-GY
74/417
7-pin green
No. Dashboard harness Climate control system harness
174/409:18Connector
BU-GY
3/112 Climate control system
RD
273/4010Branching point
BN-VT
3/112 Climate control system
YE
374/401:1Connector
74/409:15 Connector
WH-GN
3/112 Climate control system
GN
473/4012Branching point
BK-WH
3/112 Climate control system
BU
574/401:4Connector
VT-BN
3/112 Climate control system
PK
674/401:3Connector
YE-VT
3/112 Climate control system
BN
774/401:5Connector
WH-GN
3/112 Climate control system
GN
74/418
6-pin gray
No. Harness FLC FLC Adapter harness
127/5C1:1Forward looking camera
WH
4/80C2:1 Forward Sensing Module
(FSM)
WH
227/5C1:2Forward looking camera
BN
4/80C2:2 Forward Sensing Module
(FSM)
BN
327/5C1:3Forward looking camera
GN
4/80C2:3 Forward Sensing Module
(FSM)
GN
427/5C1:4Forward looking camera
PK
4/80C2:4 Forward Sensing Module
(FSM)
PK
527/5C1:5Forward looking camera
GY
4/80C2:5 Forward Sensing Module
(FSM)
GY
627/5C1:6Forward looking camera
YE
4/80C2:6 Forward Sensing Module
(FSM)
YE
S27/5C1:SForward looking camera
-
4/80C2:S Forward Sensing Module
(FSM)
-
Connector
74/414 - 74/418
