Volvo XC70 2012 - Page 230

TP 39217202 XC70(08-) & S80(07-) 2012 230
74/419
2-pin blue
No. Dashboard harness Infotainment harness
116/60C5:1Phone Module (PHM)
WH
16/47C1:1 Antenna GSM/GPS/RDAR
WH
1S 16/60C5:1S Phone Module (PHM)
-
16/47C1:1S Antenna GSM/GPS/RDAR
-
74/420
5-pin gray
No. Dashboard harness Tunnel harness
116/1C5:1Integrated Audio Module (IAM)
RD
17/42C1:1 USB-port
RD
216/1C5:2Integrated Audio Module (IAM)
WH
17/42C1:2 USB-port
WH
316/1C5:3Integrated Audio Module (IAM)
GN
17/42C1:3 USB-port
GN
416/1C5:4Integrated Audio Module (IAM)
BK
17/42C1:4 USB-port
BK
516/1C5:5Integrated Audio Module (IAM)
-
17/42C1:5 USB-port
-
74/501
5-pin green
No. Floor harness Tunnel harness
173/5021Branching point
BN-VT
3/65:3 Switch, heated rear seat
BN-VT
24/93C2:14Keyless Vehicle Module (KVM)
GY-VT
16/135:1 Antenna, door lock,
passenger compartment 2
GY-VT
34/93C2:17Keyless Vehicle Module (KVM)
BU-WH
16/135:2 Antenna, door lock,
passenger compartment 2
BU-WH
4 4/93C1:4 Keyless Vehicle Module (KVM)
GN-RD
16/134:2 Antenna, door lock,
passenger compartment 3
GN-RD
54/93C1:16Keyless Vehicle Module (KVM)
YE-OG
16/134:1 Antenna, door lock,
passenger compartment 3
YE-OG
74/502
2-pin gray
No. Floor harness Tunnel harness
111C/22:2Fuse in distribution box
passenger compartment
GN-OG
9/1:2 Outlet 12V front
GN-OG
273/5035Branching point, LHD
BK-VT
73/5026 Branching point
BK-VT
73/5023 Branching point, RHD
BK-GN
Connector
74/419 - 74/502
