TP 39217202 XC70(08-) & S80(07-) 2012 233
74/504
57-pin natural
No. Engine compartment harness Floor harness
26 -
-
-
-
27 -
-
-
-
28 -
-
-
-
29 -
-
-
-
30 -
-
-
-
31 -
-
-
-
32 -
-
-
-
33 -
-
-
-
34 -
-
-
-
35 -
-
-
-
36 -
-
-
-
37 74/301:33 Connector
VT-OG
74/512:2 Connector
VT-OG
38 74/301:24 Connector
74/512:3 Connector
GN-OG
74/301:24 Connector
74/512:3 Connector
GN-OG
39 74/301:31 Connector
BU-GY
74/512:4 Connector
BU-GY
40 -
-
-
-
41 74/9:7 Connector
YE-RD
74/512:14 Connector
YE-RD
42 74/301:20 Connector, Man
GY-BN
4/56C2:41 Central Electronic Module
(CEM)
4/93C5:3 Keyless Vehicle Module (KVM)
GY-BN
43 -
-
-
-
44 73/3021 Branching point
BU-BK
73/5015 Branching point
74/511:3 Connector
BU-BK
45 73/3022 Branching point
GN-BK
73/5016 Branching point
74/511:4 Connector
GN-BK
46 -
-
-
-
47 -
-
-
-
48 -
-
-
-
continues
Connector
74/504:26-48
To Next Page
