TP 39217202 XC70(08-) & S80(07-) 2012 234
74/504
57-pin natural
No. Engine compartment harness Floor harness
49 -
-
-
-
50 4/16C1:22 Brake Control Module (BCM)
VT-BN
7/164:4 Body Sensor Cluster
Stability Sensor (BSC)
VT-BN
51 4/16C1:29 Brake Control Module (BCM)
GN-BU
7/164:1 Body Sensor Cluster
Stability Sensor (BSC)
GN-BU
52 -
-
-
-
53 -
-
-
-
54 -
-
-
-
55 -
-
-
-
56 73/3019 Branching point
4/56C1:30 Central Electronic Module
(CEM)
GY-OG
73/5005 Branching point
73/5009 Branching point
GY-OG
57 73/3020 Branching point
4/56C1:31 Central Electronic Module
(CEM)
VT-OG
73/5006 Branching point
73/5010 Branching point
VT-OG
74/504B
2-pin red
No. Engine compartment harness Floor harness
1-
-
-
-
211A/3:2Fuse, Distribution box in engine
compartment
11A/4:2 Fuse, Distribution box in engine
compartment
RD-GN
73/5075 Branching point
RD-GN
Connector
74/504:49-57 - 74/504B
