Volvo XC70 2012 - Page 235

TP 39217202 XC70(08-) & S80(07-) 2012 235
74/507
26-pin black
No. Harness front door, left Floor harness
1 3/126C2:3 Driver Door Module (DDM)
3/127C2:3 Passenger Door Module (PDM)
GY-OG
73/5005 Branching point
GY-OG
23/126C2:15Driver Door Module (DDM)
3/127C2:15 Passenger Door Module (PDM)
VT-OG
73/5006 Branching point
VT-OG
36/36:4 Lock motor, central locking, LH
front door
GN-VT
4/56C2:11 Central Electronic Module
(CEM)
GN-VT
4 3/127C1:20 Passenger Door Module
(PDM), RHD
73/5019 Branching point, LHD
GN-WH
74/509:7 Connector
GN-WH
5-
-
-
-
6-
-
-
-
7 3/176:1 Switch, driver’s door power
window, LHD
BU-WH
73/5044 Branching point, LHD
BU-WH
8-
-
-
-
9-
-
-
-
10 -
-
-
-
11 3/273:1 Lock contact, LH front door
BU-GN
4/93C5:19 Keyless Vehicle Module
(KVM)
BU-GN
12 3/273:3 Lock contact, LH front door
YE-VT
4/93C5:21 Keyless Vehicle Module
(KVM)
YE-VT
13 6/36:4 Lock motor, central locking, LH
front door
GN-OG
4/93C4:9 Keyless Vehicle Module
(KVM)
GN-OG
14 6/36:1 Lock motor, central locking, LH
front door
GY
4/93C2:4 Keyless Vehicle Module
(KVM)
GY
15 6/36:2 Lock motor, central locking, LH
front door
VT-BK
4/93C4:1 Keyless Vehicle Module
(KVM)
VT-BK
16 -
-
-
-
17 6/62:2 Power door mirror, left
WH
74/504:1 Connector
WH
18 6/62:3 Power door mirror, left
BK-WH
74/504:2 Connector
BK-WH
19 -
-
-
-
20 3/127C1:13 Passenger Door Module
(PDM), RHD
73/5037 Branching point, LHD
73/5024 Branching point, RHD
BK-VT
73/5035 Branching point
BK-VT
21 3/126C1:2 Driver Door Module (DDM),
LHD
VT-RD
11C/8:2 Fuses in distribution box
passenger compartment,
LHD
VT-RD
3/127C1:2 Passenger Door Module
(PDM), RHD
RD
11C/9:2 Fuses in distribution box
passenger compartment,
RHD
RD
22 16/4.2:1 Left-hand front door speaker
73/5078 Branching point
GN-BK
74/407:9 Connector
GN-BK
continues
Connector
74/507:1-22
