Volvo XC70 2012 - Page 236

TP 39217202 XC70(08-) & S80(07-) 2012 236
74/507
26-pin black
No. Harness front door, left Floor harness
23 16/4.2:2 Left-hand front door speaker
73/5079 Branching point
GY-BK
74/407:1 Connector
GY-BK
24 -
-
-
-
25 7/208:1 Pressure sensor front door left
YE-RD
4/9C1:57 Supplemental restraint
system module (SRS)
YE-RD
26 7/208:2 Pressure sensor front door left
VT-OG
4/9C1:58 Supplemental restraint
system module (SRS)
VT-OG
74/508
26-pin black
No. Harness front door, right Floor harness
1 3/126C2:3 Driver Door Module (DDM)
3/127C2:3 Passenger Door Module (PDM)
GY-OG
73/5009 Branching point
GY-OG
23/126C2:15Driver Door Module (DDM)
3/127C2:15 Passenger Door Module (PDM)
VT-OG
73/5010 Branching point
VT-OG
36/55:4 Lock motor, central locking, RH
front door
BK-GN
4/56C2:29 Central Electronic Module
(CEM)
BK-GN
4 3/127C1:20 Passenger Door Module
(PDM), LHD
73/5019 Branching point, RHD
GN-WH
74/510:7 Connector
GN-WH
5-
-
-
-
6-
-
-
-
7 3/176:1 Switch, driver’s door power win-
dow, RHD
BU-WH
73/5044 Branching point, RHD
BU-WH
8-
-
-
-
9-
-
-
-
10 -
-
-
-
11 3/274:1 Lock contact, RH front door
GN-RD
4/93C5:2 Keyless Vehicle Module
(KVM)
GN-RD
12 3/274:3 Lock contact, RH front door
BU-GY
4/93C5:22 Keyless Vehicle Module
(KVM)
BU-GY
13 6/55:2 Lock motor, central locking, RH
front door
GY-BN
4/93C4:22 Keyless Vehicle Module
(KVM)
GY-BN
14 6/55:4 Lock motor, central locking, RH
front door
BU-RD
4/93C2:5 Keyless Vehicle Module
(KVM)
BU-RD
15 6/55:3 Lock motor, central locking, RH
front door
GN-VT
4/93C4:2 Keyless Vehicle Module
(KVM)
GN-VT
16 -
-
-
-
17 -
-
-
-
18 -
-
-
-
19 -
-
-
-
continues
Connector
74/507:23-26 - 74/508:1-19
