Volvo XC70 2012 - Page 237

TP 39217202 XC70(08-) & S80(07-) 2012 237
74/508
26-pin black
No. Harness front door, right Floor harness
20 3/127C1:13 Passenger Door Module
(PDM), LHD
73/5024 Branching point, LHD
73/5037 Branching point, RHD
BK-GN
73/5023 Branching point
BK-GN
21 3/126C1:2 Driver Door Module (DDM),
RHD
VT-RD
11C/8:2 Fuses in distribution box
passenger compartment
VT-RD
3/127C1:2 Passenger Door Module
(PDM), LHD
RD
11C/9:2 Fuses in distribution box
passenger compartment
RD
22 16/3.2:1 Right-hand front door speaker
73/5076 Branching point
VT-BK
74/407:11 Connector
VT-BK
23 16/3.2:2 Right-hand front door speaker
73/5077 Branching point
YE-BK
74/407:3 Connector
YE-BK
24 -
-
-
-
25 7/209:1 Pressure sensor front door right
YE-RD
4/9C1:56 Supplemental restraint sys-
tem module (SRS)
YE-RD
26 7/209:2 Pressure sensor front door right
VT-OG
4/9C1:55 Supplemental restraint sys-
tem module (SRS)
VT-OG
74/509
16-pin black
No. Harness rear door left Floor harness
13/128:2Left rear door module (LDM)
BU-RD
11C/11:2 Fuse in distribution box
passenger compartment
BU-RD
23/128:13Left rear door module (LDM)
73/5036 Branching point
BK-VT
73/5035 Branching point
BK-VT
316/6:1 Left-hand rear door speaker
GN-RD
74/407:12 Connector
GN-RD
416/6:2 Left-hand rear door speaker
GY-RD
74/407:4 Connector
GY-RD
56/57:4 Lock motor, central locking, LH
rear door
GN
4/56C2:10 Central Electronic Module
(CEM)
GN
6-
-
-
-
73/128:20Left rear door module (LDM)
GN-WH
74/507:4 Connector
GN-WH
8 3/275:5 Lock contact, LH rear door
YE
4/93C1:15 Keyless Vehicle Module
(KVM)
YE
9 3/275:4 Lock contact, LH rear door
GN-BN
4/93C1:3 Keyless Vehicle Module
(KVM)
GN-BN
10 6/57:2 Lock motor, central locking, LH
rear door
BU-BN
4/93C3:2 Keyless Vehicle Module
(KVM)
BU-BN
11 6/57:1 Lock motor, central locking, LH
rear door
YE-BU
4/93C3:2 Keyless Vehicle Module
(KVM)
YE-BU
12 6/57:4 Lock motor, central locking, LH
rear door
VT-OG
4/93C5:15 Keyless Vehicle Module
(KVM)
VT-OG
13 3/275:1 Lock contact, LH rear door
GY-OG
4/93C5:17 Keyless Vehicle Module
(KVM)
GY-OG
14 3/275:3 Lock contact, LH rear door
GN-OG
4/93C5:4 Keyless Vehicle Module
(KVM)
GN-OG
15 -
-
-
-
16 -
-
-
-
Connector
74/508:20-26 - 74/509
