Volvo XC70 2012 - Page 238

TP 39217202 XC70(08-) & S80(07-) 2012 238
74/510
16-pin black
No. Harness rear door right Floor harness
13/129:2Right rear door module (RDM)
YE-RD
11C/10:2 Fuse in distribution box
passenger compartment
YE-RD
23/129:13Right rear door module (RDM)
73/5025 Branching point
BK-GN
73/5023 Branching point
BK-GN
316/5:1 Right-hand rear door speaker
VT-RD
74/407:13 Connector
VT-RD
416/5:2 Right-hand rear door speaker
YE-RD
74/407:5 Connector
YE-RD
56/56:4 Lock motor, central locking, RH
rear door
YE
4/56C2:28 Central Electronic Module
(CEM)
YE
6-
-
-
-
73/129:20Right rear door module (RDM)
GN-WH
74/508:4 Connector
GN-WH
8 3/276:5 Lock contact, RH rear door
BU-OG
4/93C1:14 Keyless Vehicle Module
(KVM)
BU-OG
9 3/276:4 Lock contact, RH rear door
VT-GY
4/93C1:23 Keyless Vehicle Module
(KVM)
VT-GY
10 6/56:3 Lock motor, central locking, RH
rear door
GY-BK
4/93C3:1 Keyless Vehicle Module
(KVM)
GY-BK
11 6/56:4 Lock motor, central locking, RH
rear door
GN
4/93C2:3 Keyless Vehicle Module
(KVM)
GN
12 6/56:2 Lock motor, central locking, RH
rear door
YE-RD
4/93C4:21 Keyless Vehicle Module
(KVM)
YE-RD
13 3/276:1 Lock contact, RH rear door
VT-RD
4/93C5:5 Keyless Vehicle Module
(KVM)
VT-RD
14 3/276:3 Lock contact, RH rear door
GY-RD
4/93C5:20 Keyless Vehicle Module
(KVM)
GY-RD
15 -
-
-
-
16 -
-
-
-
74/511
22-pin gray
No. Floor harness Left rear axle harness
111C/29:2Fuse in distribution box
passenger compartment
WH-VT
74/520:6 Connector
GN-RD
2-
-
-
-
373/5015Branching point
74/504:44 Connector
BU-BK
74/520:1 Connector
BU-BK
473/5016Branching point
74/504:45 Connector
GN-BK
74/520:2 Connector
GN-BK
5-
-
-
-
674/504:12Connector
GN-RD
7/56:2 Sensor ABS, rear left
BN
774/504:11Connector
BU-OG
7/56:1 Sensor ABS, rear left
WH
8-
-
-
-
9-
-
-
-
10 -
-
-
-
11 -
-
-
-
continues
Connector
74/510 - 74/511:1-11
