TP 39217202 XC70(08-) & S80(07-) 2012 239
74/511
22-pin gray
No. Floor harness Left rear axle harness
12 74/525:4 Connector
GN-BU
8/22:1 Shock absorber, Four-C,
rear left
GN-BU
13 74/525:5 Connector
YE-BU
8/22:2 Shock absorber, Four-C,
rear left
YE-BU
14 74/525:1 Connector
YE-GN
7/120:5 Height sensor, suspension,
rear left
YE-GN
15 74/525:2 Connector
GN-BN
7/120:1 Height sensor, suspension,
rear left
GN-BN
16 74/525:3 Connector
VT-WH
7/120:4 Height sensor, suspension,
rear left
VT-WH
17 74/504:18 Connector
YE-OG
4/83:5 Fuel pump control module
YE-OG
18 4/56C2:51 Central Electronic Module
(CEM)
GN-BU
6/33:1 Fuel pump
26/5 DC/AC converter, fuel tank
GN-BU
19 4/56C2:33 Central Electronic Module
(CEM)
YE-VT
6/33:2 Fuel pump
YE-VT
20 4/56C2:15 Central Electronic Module
(CEM)
GN-OG
6/33:6 Fuel pump
GN-OG
21 -
-
-
-
22 -
-
-
-
74/512
14-pin gray
No. Floor harness Harness rear axle right
1-
-
-
-
274/504:37Connector
VT-OG
6/67:1 Pump, fuel leakage control
VT-OG
374/504:38Connector
GN-OG
6/67:2 Pump, fuel leakage control
GN-OG
474/504:39Connector
BU-GY
6/67:3 Pump, fuel leakage control
BU-GY
574/504:5Connector
YE-BK
7/57:1 Right-hand rear ABS sensor
WH
674/504:6Connector
BU-RD
7/57:2 Right-hand rear ABS sensor
BN
774/504:21Connector
BU
6/67:4 Pump, fuel leakage control
9/38:1 Electrically heated fuel filter
BU
831/68 Ground connection
BK-OG
6/35:2 Fuel pump, auxiliary heater
9/38:2 Electrically heated fuel filter
BK-OG
94/56:36Central Electronic Module
(CEM)
YE-GN
7/121:5 Height sensor, suspension,
rear right
YE-GN
10 4/56:53 Central Electronic Module
(CEM)
GN-BN
7/121:1 Height sensor, suspension,
rear right
GN-BN
11 4/56:35 Central Electronic Module
(CEM)
GN-VT
7/121:4 Height sensor, suspension,
rear right
GN-VT
12 -
-
-
-
13 -
-
-
-
14 74/504:41 Connector
YE-RD
6/35:1 Fuel pump, auxiliary heater
YE-RD
Connectors
74/511 - 74/512
