Volvo XC70 2012 - Page 240

TP 39217202 XC70(08-) & S80(07-) 2012 240
74/513
5-pin green
No. Infotainment harness Harness rear axle right
1 4/84C1:5 Suspension Module (SUM)
VT-GY
8/23:1 Shock absorber, Four-C,
rear right
VT-GY
2 4/84C1:4 Suspension Module (SUM)
BU-BN
8/23:2 Shock absorber, Four-C,
rear right
BU-BN
373/5066Branching point
YE-GN
7/121:5 Shock absorber, Four-C,
rear right
YE-GN
473/5053Branching point
YE-GN
7/121:1 Shock absorber, Four-C,
rear right
GN-BN
54/84C1:14Suspension Module (SUM)
GN-VT
7/121:4 Shock absorber, Four-C,
rear right
GN-VT
74/514
4-pin gray
No. Floor harness Left rear axle harness
14/115C1:29Park Brake Module (PBM)
BU-GN
6/146:2 Lock motor, rear left brake
disc
BU-GN
24/115C1:14Park Brake Module (PBM)
VT-BK
6/146:1 Lock motor, rear left brake
disc
VT-BK
34/56C2:76Central Electronic Module
(CEM)
YE-OG
4/83:4 Fuel pump control module
YE-OG
6/33:4 Fuel pump
YE-GY
431/65 Ground connection
BK-YE
74/520:4 Connector
BK
74/520:5 Connector
BK-YE
74/518
2-pin gray
No. Infotainment harness Floor harness
14/84C1:16Suspension Module (SUM)
BU-BK
73/5015 Branching point
74/409:23 Connector
BU-BK
24/84C1:15Suspension Module (SUM)
GN-BK
73/5016 Branching point
74/409:22 Connector
GN-BK
Connectors
74/513 - 74/518
