Volvo XC70 2012 - Page 241

TP 39217202 XC70(08-) & S80(07-) 2012 241
74/519
22-pin gray
No. Infotainment harness Engine compartment harness
1 4/84C1:6 Suspension Module (SUM)
BU-BK
8/20:1 Shock absorber, Four-C,
front left
BU-BK
2 4/84C1:7 Suspension Module (SUM)
VT-BN
8/20:2 Shock absorber, Four-C,
front left
VT-BN
3 4/84C1:9 Suspension Module (SUM)
GY-YE
8/21:1 Shock absorber, Four-C,
front right
GY-YE
4 4/84C1:8 Suspension Module (SUM)
BU-OG
8/21:2 Shock absorber, Four-C,
front right
BU-OG
573/5052Branching point
YE-GN
7/118:5 Height sensor, suspension,
front left
YE-GN
64/84C1:12Suspension Module (SUM)
BU-RD
7/118:4 Height sensor, suspension,
front left
BU-RD
773/5066Branching point
YE-GN
73/3077 Branching point
YE-GN
84/84C1:27Suspension Module (SUM)
GY-VT
7/119:4 Height sensor, suspension,
front right
GY-VT
94/84C1:22Suspension Module (SUM)
BU-GY
7/88:1 Acceleration sensor,
Four-C, front right
BU-GY
10 4/84C1:10 Suspension Module (SUM)
VT-RD
7/87:1 Acceleration sensor,
Four-C, front left
VT-RD
11 4/84C1:19 Suspension Module (SUM)
GN-BN
73/3078 Branching point
GN-BN
12 4/86C2:2 Parking Assistance Module
(PAM)
VT-GY
74/309:4 Connector
VT-GY
13 4/86C2:5 Parking Assistance Module
(PAM)
BU-GN
74/309:5 Connector
BU-GN
14 4/86C2:1 Parking Assistance Module
(PAM)
YE-OG
74/309:6 Connector
YE-OG
15 4/86C2:6 Parking Assistance Module
(PAM)
BU-BK
74/309:10 Connector
BU-BK
16 4/86C2:7 Parking Assistance Module
(PAM)
BU-GY
74/309:11 Connector
BU-GY
17 4/86C2:8 Parking Assistance Module
(PAM)
BU-OG
74/309:12 Connector
BU-OG
18 -
-
-
-
19 -
-
-
-
20 -
-
-
-
21 -
-
-
-
22 -
-
-
-
Connectors
74/519
