Volvo XC70 2012 - Page 242

TP 39217202 XC70(08-) & S80(07-) 2012 242
74/520
6-pin gray
No. Left rear axle harness All wheel drive harness
174/511:3Connector
BU-BK
4/82C1:8 Differential Electronic
Module (DEM)
BU-BK
274/511:4Connector
GN-BK
4/82C1:7 Differential Electronic
Module (DEM)
GN-BK
3-
-
-
-
474/514:4Connector
BK
4/82C1:4 Differential Electronic
Module (DEM)
BK
574/514:4Connector
BK-YE
4/82C1:2 Differential Electronic
Module (DEM)
BK-YE
674/511:1Connector
GN-RD
4/82C1:1 Differential Electronic
Module (DEM)
GN-RD
74/523
6-pin gray
No. Harness parking assistance adp. Harness bumper rear
14/86C3:11Parking Assistance Module
(PAM)
BU-WH
73/5064 Branching point
BU-WH
24/86C3:2Parking Assistance Module
(PAM)
YE-GY
7/133:2 Rear parking assistance
sensor
YE-GY
34/86C3:3Parking Assistance Module
(PAM)
YE-BK
7/132:2 Rear parking assistance
sensor
YE-BK
44/86C3:4Parking Assistance Module
(PAM)
YE-OG
7/134:2 Rear parking assistance
sensor
YE-OG
54/86C3:5Parking Assistance Module
(PAM)
YE-GN
7/131:2 Rear parking assistance
sensor
YE-GN
64/86C3:8Parking Assistance Module
(PAM)
GN-WH
73/5067 Branching point
GN-WH
74/524
2-pin gray
No. Harness rear axle right Floor harness
14/115C1:12Park Brake Module (PBM)
YE-GY
6/147:1 Lock motor, rear right brake
disc
YE-GY
24/115C1:27Park Brake Module (PBM)
GN-BN
6/147:2 Lock motor, rear right brake
disc
GN-BN
Connectors
74/520 - 74/524
