Volvo XC70 2012 - Page 243

TP 39217202 XC70(08-) & S80(07-) 2012 243
74/529
2-pin black
No. Infotainment harness Harness digital radio/SUB
116/105C4:2Audio module (AUD), LHD
16/108C3:2 Multimedia Module (MMM)
OG
16/145C3:1 Remote Digital Audio
Receiver (RDAR)
16/162C3:1 Digital Audio Broadcast
Module (DABM)
16/79C2:1 Subwoofer Module (SUB)
OG
274/404:1Connector
OG
16/79C2:2 Subwoofer Module (SUB)
16/145C3:2 Remote Digital Audio
Receiver (RDAR)
16/162C3:2 Digital Audio Broadcast
Module (DABM)
OG
74/530
14-pin gray
No. Infotainment harness DAB Adapter harness
1-
-
-
-
2-
-
-
-
3-
-
-
-
4-
-
-
-
5-
-
-
-
6-
-
-
-
7-
-
-
-
873/5023Branching point
BK-GN
73/5026 Branching point
BK-GN
9-
-
-
-
10 -
-
-
-
11 -
-
-
-
12 -
-
-
-
13 -
-
-
-
14 -
-
-
-
74/531
2-pin gray
No. Infotainment harness DAB Adapter harness
116/47C2:1Antenna GSM/GPS/RDAR
WH
16/162C2:1 Digital Audio Broadcast
Module (DABM)
WH
1S 16/47C2:1S Antenna GSM/GPS/RDAR
-
16/162C2:1S Digital Audio Broadcast
Module (DABM)
-
Connectors
74/529 - 74/531
