TP 39217202 XC70(08-) & S80(07-) 2012 244
74/532
2-pin gray
No. Floor harness DAB Adapter harness
116/16C4:1Amplifier window antenna, V70
16/16C3:2 Amplifier window antenna, S80
WH
16/162C2:2 Digital Audio Broadcast
Module (DABM)
WH
1S 16/16C4:1S Amplifier window antenna,
V70
16/16C3:2S Amplifier window antenna,
S80
-
16/162C2:2S Digital Audio Broadcast
Module (DABM)
-
74/534
4-pin gray
No. Floor harness Infotainment harness
173/5117Branching point
RD
16/105C3:1 Audio module (AUD)
73/5116 Branching point
RD
211C/17:2Fuse in distribution box passen-
ger compartment
74/409:14 Connector
RD
16/145C1:1 Remote Digital Audio
Receiver (RDAR)
16/162C1:1 Digital Audio Broadcast
Module (DABM)
RD
3-
-
-
-
4-
-
-
-
74/542
5-pin green
No. Floor harness Infotainment harness
1-
-
-
-
2 16/45C6:1 Portable navigation system
YE-BU
73/5091 Branching point
YE-BU
3 16/45C6:3 Portable navigation system
VT-OG
74/535:2 Connector
VT-OG
4-
-
-
-
74/601 S80
10-pin gray
No. Trunk lid harness Floor harness
110/3:2 License plate lighting
BK
4/56C2:48 Central Electronic Module
(CEM)
YE-VT
2 6/8:3 Central locking motor, trunk lid
BK
4/56C2:30 Central Electronic Module
(CEM)
YE-OG
310/3:3 License plate lighting
BK
4/56C2:24 Central Electronic Module
(CEM)
4/93C5:18 Keyless Vehicle Module
(KVM)
BU-RD
473/5038Branching point
BK
73/5105 Branching point
BK-OG
5 6/8:1 Central locking motor, trunk lid
BK
4/56C2:63 Central Electronic Module
(CEM)
YE-VT
6 6/8:4 Central locking motor, trunk lid
BK
10/127:4 Lighting, cargo
compartment, left-hand side
10/128:4 Lighting, cargo compart-
ment, right-hand side
BK-BU
7-
-
-
-
8-
-
-
-
9-
-
-
-
10 -
-
-
-
Connectors
74/532 - 74/601
